Self Contained Upright Glass Door Freezer Low Temperature 3 4 5 6 Doors

Upright Glass Door Freezer –Self-contained Low-Temperature 3/4/5/6 doors

Our supermarket freezer(Low Temp) is ideal for  meat  or frozen food , easy to be combined to any possible length you want . Once positioned in the store it simply connect to a standard power oultet, which greately reduces expensive installation costs.

Ideal for all supermarket frozen food, ice cream

• Vertical LED lighting for energy efficiency
• Heavy-duty front bumper
• Anti-Fog Film
• Structural steel sub-frame with level adjustment
• 100mm high density polyurethane insulation for energy efficiency
• Digital case controller with temperature display
• Three adjustable tilt shelves for 1650mm high doors
• Four adjustable tilt shelves for 1800mm high doors
• Door widths – 750mm or 900mm
• Low energy Tropical Highlight series doors, or
• Ultra efficient Non-Heated Highlight series doors
• 5-door case has a TEC of 2200 watts per hour
• 20amp single phase/3 phase dedicated circuit, case dependant

What makes ourself-contained supermarket freezer a better option:

1)100mm polyurethane insulation for energy efficiency, Double the insulation = ½ the heat leak into the case

2)Tropical Highlight Series glass doors have extremely low heat leak and are probably the most energy efficient doors available.

3)Freezer cases are hot gas defrost and have a heat collector to collect waste heat during the run cycle which it reuses on defrost cycle. 12-minute defrost at low energy cost, no electric elements to fail.

4)Cases evaporate the wastewater using waste heat from the compressor.

5)Small gas charge, gas and stock loss liability from any leak is limited.

6)Stock shrinkage is reduced by glass door cases through better temperature and humidity control.

7)Low energy consumption/minimal heat load.

8)Low noise level.

9)Glass doors reduce the heat load by up to 75% when compared to open front cases.

10)All high quality components, made to last.

FAQ:

What is BEST CONVENIENCE refrigeration solutions for Convenience stores ?

THAT IS Upright display + Self contained + Big refrigeration Volume +Energy saving

ISLAND Cabinet? —NO, convenience store does not have luxury space than that of supermarket or hypermarket. Island cabinet is not friendly for him.

UPRIGHT Display? —YES, with only 50—150sqm space, how to display more cold products to customers ? Upright glass door reach-in display cabinet is the wise choice.

PLUG-IN(self contained)—YES

BIG refrigeration volume?—YES

Energy Saving?—-YES

JOY Self-contained glass door reach-in display case —- A super choice for convenience stores for dairy, produce, F&V, meat, beverage& beer, frozen food and ice cream, easy to be comined to any possible length you want.

Available in medium and low temperature models for a variety of products.
Available from 4 doors to 8 doors ( case length from 3.6m to 5.5m with display volume from 4212L to 6318L, case height : 2m and 2.2m both options), It can meet most of convenience stores requirement , amazing how much product this cabinet holds.

JUST PLUG IN—This self-contained refrigeration system greatly reduces expensive installation costs, It require nothing more than a domestic power point. once positioned in the store it simply connect to a standard power outlet .

No external pipework, no floor waste drains. An ideal product for buildings that may not have been designed for refrigeration applications. Station, business building, residential area, no matter your convenience stores positioned, JOY self-contained reach-in merchandiser can do a super job.

No fuss and no delay, install in a fraction of the time.
Low gas charges. Completely reliable refrigeration with high energy efficiency. Hot gas defrost and low energy doors and EC fan motors consumption

Give us a call to talk about your requirements.
